Offer Number |
382111 |
Manufacturer |
BOBST |
Model |
SP 104-E |
Year |
2002 |
Counter |
|
In Production |
Yes |
Upon Request
Description
centerline, <>pull mark left, <>push mark right, <>gripper edge separation, <>41cm elevated,<>Bobst-Cube control, <>micrometer adjustment, <>electric double sheet control,<>1 upper die cutting frame,<>1 die cutting plate 4 mm, <>1 upper stripping frame, <>1 lower stripping frame,<> max. machine speed 7000 sheets/hour, <>max. pressure 250 tons, <>processable materials: paper min. 80g/m², <>cardboard up to max. 2000g/m², <>corrugated cardboard up to 4mm<>Stripping station<>Non-stop in feeder + delivery<>Repainted
Technical Details
- Sheet size max: 1040x740 mm
- Sheet size min.: 400x350 mm
- Gripper margin: 1.040+740 mm
- Platen pressure max.: 250 t
- Production speed: 8500 cycles/h.
- Mechanical speed: 8500 sheets/h.
- HS Code: 84439959 HS Codes Classification of Other
Offer Details
- Brand: BOBST
- Model: SP 104-E
- Condition: Good
- Year: 2002
- Country: Europe
- Under Power: Yes
- Still in production: Yes
- Test possible: Yes
- Complete and in working condition: Yes
