Offer Number |
379274 |
Manufacturer |
KOLBUS |
Model |
DA 270 |
Year |
2003 |
Counter |
|
In Production |
Yes |
Upon Request
Description
Production of hardcover books, filing cabinets and table games<>Automatic measurement setting system<>Carton feeding tape<>Automatic cardboard feeder<>Double roll holder with automatic feeding and cutting to make covers with round loin<>Liner feeder<>Gluing unit with pre-heated gelatin tank<>Check the viscosity of the glue with viscometer and pump for water control<>Roller press<>Roll tape output with counter. Exit to the right with possibility to left<>CORNER CUTTING KOLBUS ECK 100 <>Technical specifications:<>Size range opened case (min) 205 x 140 mm<>Size range opened case (max) 670 x 390 mm<>Join width: 4 - 15 mm<>Width between boards: 14 - 120 mm<>Turn width, closed 8 - 15 mm<>Cloth with: 223 - 708 mm<>Cloth height: 130 - 428 mm<>Boards:<>Thickness: 1 - 4mm<>Width: 95 - 328 mm<>Height: 140 - 390 mm
Technical Details
- Cover size max.: 670x390 mm
- Cover size min.: 205x140 mm
- Cloth height: 130 - 428 mm
- Cloth width: 223 - 708 mm
- Cardboard thickness: 1 to 4 mm
- Cardboard width: 95 - 328 mm
- Cardboard height: 140 - 390 mm
- Joint width: 4- to 15 mm
- Spine width: 14- to 120 mm
- Turn in width closed: 8 - to 15 mm
- Centre strip roll thickness / width: 03, to 0,6 mm / 6- to 90 mm
- Mechanical speed: 65 cycles/min.
- HS Code: 84439959 HS Codes Classification of Other
Offer Details
- Brand: KOLBUS
- Model: DA 270
- Condition: Good
- Year: 2003
- Country: Europe
- Under Power: Yes
- Still in production: Yes
- Test possible: Yes
- Complete and in working condition: Yes
