| Description: |
Printing technology UV “Fixed Array” inkjet print-heads<>Media handling Scodix Twin-Tray™ technology (TT)<>Resolution Up to 2,540 x 450 DPI<>Variable data PDF, Optional Barcode system<>Supported image standards Standard PDF<>Scodix RSP™ Technology Up to 4 CCD cameras system, Automatic positioning<>Communication protocol Hot Folder, LAN<>Substrates* Offset, Digital, Plastics, Laminated and coated substrates<>Substrates loading sizes<>Minimum L297 x W420 mm / 11.7 x 16.5 in<>Maximum – L545 x W788 mm / 21.5 x 31 in<>Printing Image size Maximum – L504 x W748 mm / 19.86 x 29.5 in<>Polymer<>Scodix PolySENSE™ Clear Polymer<>Scodix Spot™ - Flat, Clear Polymer<>Polymer layer thickness From 5 Up to 250 microns<>Print Heads Maintenance Automatic process<>Substrates input system Automatic feeder<>Substrates output systems Automatic stacker<>Substrates weight 135 - 675 gsm / 6 - 30 points<>Substrates thickness Up to 700 micron<>Air requirements Air Flow: 34 CFM. 7 bar +/-1 - regulated<>Scodix software Internal RIP, Software Editor<>Press dimensions (L x H x W) 6,327 x 1,788 x 1,889 mm / 249 x 71 x 74 in<>Operating environment<>Temperature: 15ºC to 30ºC (59ºF - 86ºF)<>Humidity: 40% to 80% relative humidity, non-condensing<>Electrical requirements<>Voltage: 3x220, +/-5% 3 Phases + G + N (star connection)<>Frequency: 50 /60 Hz<>Current: Avg. 25 Amps in production<>Power consumption:<> Avg.: 13.5 kVA in production<> Max.: 30 kVA<>Circuit Breaker: 44 Amps minimum<>Multi Polymer Tank System Up to 4 tanks (3 Polymers and flushing fluid)<>Polymer Switch System Automatic Polymer Switch System<>Press weight (Net) 4,400 kg / 9,700 lbs. |
