Offer 379337

UTECO ONYX 876 GL (1450) from 2006

Central Impression Presses

Offer Details

Name property Description property
Offer Number: 379337
Brand: UTECO
Model: Onyx 876 GL (1450)
Manufacturer UTECO
Condition: Good
Year: 2006
Incoterm: EX Works
Cylinders Condition:
Under Power: Yes
Still in production: Yes
Test possible: Yes
Complete and in working condition: Yes
Availability:
Counter:
Machine number:
Description: Flexo CI Gearless<>Drying System: LPG Gas<>Repeat: 380 – 800 mm<>Mechanical Speed: 365 m/minute<>Doctor Blade Chamber<>Maximum Material width: 1410 mm<>Unwinder Turret - 800 OD<>Rewinder Turret- 800 OD<>Sleeve<>Anilox Rollers<>HMI Control unit for Sleeve change/Temperature/Tension, and register<>3 x keypad controls<>Camera ReVision<>BST Edge guides for the rewind and unwind<>Chill Roll unit with Corema Chiller unit<>Allen Bradley PLC<>Control Techniques Drives for Cliché and Anilox<>Software upgraded in 2023<>Gas drying system with an automatic air recirculation system<>Anilox- 4x475 ,4x320, 2x260, 1x200, 1x220, 1x140, 2x120, 2x160, 1x180, 2x100, 1x80<>Sleeves-16x380, 8x400, 8x410. 8x420, 10x430, 8x450, 9x490, 8x500, 8x510, 8x520, 16x530, 12x600,8x570, 8x580, 8x600,16x620, 8x630, 8x640, 8x650, 9x660, 8x670, 8x690, 8x700, 8x750, 8x790, 8x800

Technical details

Name property Description property
Max. Web width: 1450 mm
Printing repeat (max): 380 – 800 mm
Max mechanical Speed 365 m/min
HS Code 84431600

PRICE: Upon request

Images
