Offer 381748, a MBO COBO-STACK from 2022
Folding Machines Components
Offer Number |
381748 |
Manufacturer |
MBO |
Model |
Cobo-Stack |
Year |
2022 |
Availability |
Immediately |
Counter |
|
In Production |
NO |
Upon Request
Description
CoBo Stack<>- Cobot (no safety cage required)<>- Two pallet positions possible; this allows one pallet to be prepared while the other is being loaded<>- Visual and audible signals to indicate different operating states<>- Standard left-hand output<>- RAS router included; remote maintenance access can be enabled by the customer<>- Electrically prepared for use with MBO A80 delivery<>Infeed height: 803 mm - 923 mm<>Stacking height: 60 mm - 150 mm<>Maximum stack weight: 6 kg<>Maximum stacks per hour: 300<>Maximum pallet height: 900 mm<>Gripper M (Medium):<>Product height: 210 mm - 340 mm<>Product width: 155 mm - 235 mm<>Adjustable stacking height to 1,400 mm by adjusting the robot arm height<>by 500 mm<>Mechanical connection to MBO A500 I 4700, palamides alpha500l 700 and alphaSooptus /<>700plus, A80
Technical Details
- Infeed height:: 803 mm - 923 mm
- Stack height:: 60 mm - 150 mm
- Stack per hour:: 300
- Pallet height:: 900 mm
Offer Details
- Brand: MBO
- Model: Cobo-Stack
- Condition: Very good
- Year: 2022
- Country: Europe
- Under Power: NO
- Still in production: No
- Test possible: No
- Complete and in working condition: Yes
- Available: Immediately
